MAIN DESCRITION
10/100/1000Base-TX to 100/1000Base-FX Media Converter is the first media converter in the market
to fulfill 100/1000M auto-sensation at fiber optic port, which increase the flexibility of the whole network.
It complies with IEEE802.3, IEEE802.3u, IEEE802.3z, IEEE802.3ab standards and supports the connection
between 10Base-T, 10Base-TX, 1000Base-T, 100Base-FX and 1000Base-SX/LX.
FEATURES
² Support inter-conversion between 1000Base-T and 1000Base-SX/LX
² 100/1000Base-FX auto-sensed
² Unique patented converter which supports both 100Mbps and 1 Gbps at the fiber port using the
same SFP module
² Auto-negotiation or Manual mode (10M, 100M & 1000M) at TP port
² High compatibility capacity: compatible with the network card, hub, switch and repeater of other brands
² Support full/half duplex auto-sensed
² Support MDI/MDI-X auto-sensed
² Support the transmission of Qos packets
² Support the transmission of VoIP packets
