Main Description
It belonged to the switch of 2000series,4 ports for 1000 Base SC, single mode and multi mode, single fiber
and dual fibers can be selected;the max transporting distance can reach 120km, It adopts high quality network switch chip,
and its all ports support non-blocking, across the packet forwarding; it is very suitable for data communication,video monitoring
and relay transmission equipment during to flexible and simple usage.
Technical parameters
(1) Operating standards:IEEE802.3/u/z/ab,10/100/1000Base-T and 1000Base-SX/LX
(2) Flow control
Full Duplex: IEEE802.3x flow control
Half duplex: back pressure flow control
(3) Connector: UTP: RJ-45:10/100/1000Mbps; fiber port: 1000Mbps
(4).Ultra-low time-delay date transmission, completely transparent to the network protocol
(5).Port support IEEE802.X VLAN, port monitoring.IPV6 port monitoring flux is 4K,base on MARC`s Trunking
(6)Effectiveness of automatic link transfer
(7).Support for spanning tree and loop detection,IGMP,MLD
(8)Bult-in 9720Bytes long data packet
(9) Cable: UTP: Cat.5 or 6 UTP (the max distance up to 120m)
Multimode Fiber:50/125,62.5/125μm (the max distance up to 2KM)
Single mode Fiber: 9/125μm (the max distance up to 120km)
(10).Support 2 ports for SFP/FC/SC, to feel free to select optic modules for SFP/FC/SC to achieve single/multi mode or different transporting distances.
(11).Support hot-swappable, plug and play
Dynamic feedback the status for link connection and fault detect.
