SDI Input
|
|
Signal Type SDI
|
SMPTE 424M, SMPTE 292M, SMPTE 259M
|
|
Data Rates
|
270Mbit/s - 1.48Gbit/s - 3Gbit/s
|
|
Cable Equalization
|
Automatic cable EQ (Belden 1694A cable)
250m @ 270Mbit/s, 140m @ 1.5Gbit/s, 80m @ 3Gbit/s
|
|
Connector
|
BNC 75 Ohm
|
|
Number of tranmitter channel
|
1
|
|
Number of tranmitter Loopout
|
1
|
|
Number of receiver output
|
2
|
|
General：
|
|
Input Power
|
5 V DC or12 V DC
|
|
Power consumption (maximum)
|
Transmitter: 1.8W Receiver: 1.5W
|
|
Operating temperature
|
0°C to 55°C
|
|
Storage temperature
|
-10°C to 70°C
|
|
Operating humidity
|
0 ~ 95% (non-condensing)
|
|
Net Weight
|
210g /pair （with Power supply 440g/pair）
|
|
Case material
|
Aluminum
|
